Unit 4: Class 10 Math PECTAA Notes New Book

Introduction

Unit 4 of the new PECTAA Class 10 Mathematics book is about functions and their graphs. A function is a rule that gives exactly one output for every input, and it is one of the most important ideas in all of mathematics.

Functions describe how a taxi fare grows with distance, how profit depends on sales, and how one quantity changes with another. In this unit, students learn to combine functions, find inverse functions, draw absolute value graphs, and use functions to solve real-life problems. These notes follow the new book for session 2026-27 and suit students of all Punjab boards.

What You Will Learn

By the end of this unit, students will be able to:

• perform operations on functions and find composite functions;
• define inverse functions and find their domain and range;
• plot graphs of absolute valued functions;
• solve absolute value linear equations and inequalities and show the answer on a number line;
• apply functions to real-world problems such as finance, transport, and sales.

Key Topics Explained

1. Functions, Domain, and Range

If X and Y are non-empty sets, a function from X to Y assigns each element of X exactly one element of Y. The set X is the domain, Y is the co-domain, and the actual outputs form the range. If f(a) = b, then b is the image of a, and a is a pre-image of b. In y = f(x), x is the independent variable and y is the dependent variable.

2. Operations on Functions

Two functions can be added, subtracted, multiplied, and divided: (f + g)(x) = f(x) + g(x), (f − g)(x) = f(x) − g(x), (f · g)(x) = f(x) · g(x), and (f ÷ g)(x) = f(x) ÷ g(x) where g(x) ≠ 0.

3. Composite Functions

The composition of f and g is written (f∘g)(x) = f(g(x)). The inner function g works first, and then f acts on its result. In general, f∘g and g∘f are different.

4. Types of Functions and Inverse Functions

A function is one-to-one (injective) when different inputs give different outputs. It is onto (surjective) when every element of the co-domain has a pre-image. It is bijective when it is both. A function has an inverse only if it is one-to-one and onto. To find f⁻¹, write y = f(x), solve for x, and then swap the variables. The domain of f⁻¹ is the range of f, and the range of f⁻¹ is the domain of f.

5. Vertical and Horizontal Line Tests

A graph represents a function if every vertical line meets it at most once. A function is one-to-one if every horizontal line meets its graph at most once.

6. Absolute Value Functions

The absolute value function f(x) = |x| has a V-shaped graph with its vertex at the origin. For f(x) = a|x − h| + k, the vertex is at (h, k). To solve |expression| = c, write two equations: expression = c and expression = −c. For inequalities, |x| < a means −a < x < a, and |x| > a means x < −a or x > a.

7. Real-Life Problems

Functions model costs, fares, profits, and balances. Absolute value inequalities model tolerance limits, such as an allowed voltage range around a target value.

Worked Examples

Example 1 (Value of a function): If f(x) = 2x² − x, then f(3) = 18 − 3 = 15.

Example 2 (Operations): For f(x) = 3x + 1 and g(x) = x², (f + g)(x) = x² + 3x + 1 and (f · g)(x) = 3x³ + x².

Example 3 (Composition): For f(x) = 2x + 3 and g(x) = x²:
(f∘g)(x) = 2x² + 3, but (g∘f)(x) = (2x + 3)² = 4x² + 12x + 9. So f∘g ≠ g∘f.

Example 4 (Inverse): Find the inverse of f(x) = 3x − 6.
y = 3x − 6, so x = (y + 6) ÷ 3. Hence f⁻¹(x) = (x + 6) ÷ 3.

Example 5 (Absolute value equation): Solve |2x − 1| = 5.
2x − 1 = 5 gives x = 3, and 2x − 1 = −5 gives x = −2. Solution: {3, −2}.

Example 6 (Absolute value inequality): Solve |x − 2| ≤ 3.
−3 ≤ x − 2 ≤ 3, so −1 ≤ x ≤ 5.

Example 7 (Real life): A plan costs C(x) = 300 + 5x rupees for x units. For 40 units, C(40) = 300 + 200 = Rs. 500.

Important Formulas at a Glance

Exercises in Unit 4

Exam Tips

• Work out the inner function first in a composition.
• Always check that f(f⁻¹(x)) = x after finding an inverse.
• Split an absolute value equation into two cases, and check both answers.
• For graphs, mark the vertex first and then plot a few points on each side.
